Hummi_Optical Flow Laser Ranger Sensor- 25

Quantity:

SKU:{{ product.sku }}

Model: {{ product.model }}

weight: {{ product.weight }} Kilogram

Optical Flow Laser Ranger Sensor Specifications
Output Interface	UART/115200/LVTTL
Protocol	Mavlink/MSP
Output Rate	50Hz
Firmware Supported	Ardupilot/PX4/INAV/Betaflight
TOF Range TOF	6m@90% reflectance/1K Lux; 4m@90% reflectance/70K Lux
Center Wavelength	940nm
Emitting Angle	2 °
Dead Zone	2cm
Ranging Accuracy	2cm(<2m@90% reflectance); 1.5%(>2m@90% reflectance)
Optical Flow FOV	42 °
Max Speed Measurement	7m/s@1m height
Ambient Light Demand of Optical Flow	>60Lux
Optical Flow Working Distance	>8cm
Power Consumption	200mW (40mA@5V)
Supply voltage	5v
